In recent years, the instruments in checkweighers are in the development stage of changing from traditional sensors to new types of sensors. The development of MEMS has brought the miniaturization, intelligence, multi-function and reliability of sensors to a new level. The detector is based on microelectronics technology, with built-in microprocessor, test transformer or packaged micro-sensor, microprocessor and related integrated circuits, to achieve digitization, intelligence, networking and systematization.

newCheckweigher InstrumentThe development depends on new sensitive materials, testing transformer sensitive components and nanotechnology, such as new generation fiber optic sensors, superconducting sensors, focal plane array infrared detectors, biosensors, nanosensors, new quantum sensors, micro gyroscopes, networked sensors , smart sensor, fuzzy sensor, multi-function sensor, etc.

Voltage output conversion Current output conversion

●Output 05V, 15V, 010V, 420mA, 020mA, 040mA

●Voltage plus 1724V plus 1724V

●Analog input 1.0, 2.0, 3.0 mV\/V 1.0, 2.0, 3.0 mV\/V

●The input impedance is less than or equal to 10, less than or equal to

●Keyboard: 4 long-life mechanical keys

● Communication port: RS-232\/RS-485 menu setting

●Sensor excitation voltage: 5V DC

●Modular resolution: 24 bits

●A\/D conversion (output) rate: 400 times\/second

●Weighing data output rate: 6.25, 12.5, 25, 50, 100, 200 times\/second optional

●Instrument power supply: 24V DC

●Maximum current: 200 mA (including the current consumed by the 4350Ω load cell)

●Switch value: 5 inputs and 13 outputs

●Front panel: 110mm 62mm

●Case size: 126mm 92.5mm 46mm

● Opening size: 93.5mm 46.5mm

●Working environment: -2060 degrees Celsius, relative humidity 10% 85%, non-condensing

●Storage environment: -4080 degrees Celsius, relative humidity 10% 85%, non-condensing

●Working temperature -10- plus 85 degrees Celsius -10- plus 85 degrees Celsius

●Can drive 4 350ω sensors or 8 750ω sensors;

●Working humidity

●The load resistance is greater than or equal to 1.7K0500

A checkweigher is actually a device that converts a mass signal into a measurable electrical signal output. Before using the sensor, the actual working environment of the sensor must be considered. This is very important for the correct selection of the load cell. It is related to the sensor's Normal operation, safety and service life, and even the reliability and safety of the entire weighing instrument. There are qualitative differences between the old and new national standards in the basic concepts and evaluation methods of the main technical indicators of the load cell.
