The digital analog weighing transmitter has high precision and is widely used to convert the mV weak signal output by the strain pressure sensor of weighing, tension pressure, torque and other sensors into 420mA or 05V and other universal standard analog signals. Digital analog weighing The main application of the weight transmitter: It is used to convert the mV weak signal output by the sensor strain pressure sensor such as weighing, tension pressure, and torque into a standard analog signal that can be used in general, such as 420mA or 05V. It is designed to convert the sensor output and All kinds of strain gage outputs are converted to output voltage and output current. It is suitable for industrial applications and will meet your needs.

Digital and analog weighing transmitter function parameters:

Support address query: 1-32 addresses;

Standard low-pass digital filtering;

digital calibration;

Non-volatile storage of characteristic parameters;

The measurement rate can be selected;

All setting work is done through the serial port;

The measured numerical output converges quickly and is stable;

Dynamic jitter strength can be set;

Measurement signal large range: add 10mV and add 5V;

High measurement resolution: 200,000 inner codes per millivolt;

Data output speed: 240, 120, 60, 30, 15, 7, 6, 3 (if you need other speeds, please contact. It can be up to 1600);

Baud rate: 1200bps, 2400 bps, 4800 bps, 9600 bps, 19200 bps, 38400 bps (optional) up to 57600 (default);

digital analogweighing transmitterAbandoned the potentiometer of the analog transmitter, and is no longer troubled by problems such as poor contact caused by the oxidation of the potentiometer contact; due to the use of MCU digital operation processing, plus the digital filtering function that can set parameters, users use a large number of The remote sensor is used for small weighing applications, and it can still have relatively stable and high-resolution output; the highly integrated 24-bit sigma-delta ADC chip ensures that the sensor signal input from the front end of the transmitter can be stably collected, avoiding various Compared with the traditional analog type, the digital weight transmitter has better anti-interference performance; 2 buttons complete the zero point debugging and the loading point debugging , Filter parameter setting function, 1 LED indicates various work and abnormal situation prompts, concise and clear.

Digital and analog weighing transmitter can be widely used in metallurgy, electric power, petroleum, chemical industry, medicine, food, textile, water conservancy, geology and other fields to measure and control the pressure of gas, liquid and steam.
