Checkweigher Instrument It is a medium-low speed, high-precision online checkweighing equipment, which can be integrated with various production lines and conveying systems. File.On-line checkweighing has gradually become an indispensable link in the production process of current industrial production, especially the food and pharmaceutical industries. The on-line checkweigher is compared with the preset range, and the control unit sends out instructions to adjust the weight to the limit. Qualified products are rejected.

In recent years, checkweigher instruments tend to be more compact and multi-functional, and the application of checkweighers integrating metal inspection, X-ray foreign body inspection and sorting. At present, general metal inspection can detect metal foreign bodies of 0.81mm, and the inspection speed can be Up to 4060m\/min. Since the metal detector cannot detect foreign bodies such as hair, thread, bone, glass, etc., a newest X-ray foreign body detector is applied for this purpose, and the maximum detection speed can reach 65m\/min. At present, the world Countries have begun to further extend the function of checkweighers to the warehouse and packing automation management system, an integrated conveying detection that integrates weight sorting, packing geometric size detection, radio frequency automatic identification coding, and shape recognition processing. The equipment has been widely used in logistics and transportation management systems.

Checkweigher MeterIt is a non-standard customized equipment. It is transported in a special wooden box, packaged by professionals, and assigns technicians to come to the door for installation, commissioning and operation guidance. For example, the online checkweigher needs to be moved or transported again during use. When using, you need to pay attention to the following points to ensure that the checkweigher can move in good condition.

1. Use a special wooden packing box for packaging. When placing the product in the wooden box, it should be firmly cushioned, clamped firmly, fixed in the packing box with bolts, and must not be moved. Do not open the package of the checkweigher until it arrives at the installation site. , because the crate has a protective effect on it.

2. During the transportation of the online checkweigher, the sensor protection device must be in a reliable protection state, and the protection device can be released after the installation is completed.

3. The weighing conveyor belt is packaged separately and must be fixed with screws, and the fixing screws can only be loosened when they arrive at the place where they are placed.

4. When using a truck with a lifting platform or similar vehicles for transportation, the upper part of the checkweigher must be held by one person (2 people are better) to avoid it tilting.

5. When transporting an online checkweigher without a box, please fix the bracket of the checkweigher (such as the middle shelf, or the bracket of the instrument) to prevent the checkweigher from tilting.

6. It is forbidden to fix the conveyor belt (such as weighing conveyor belt, input conveyor belt or output conveyor belt) or the motor of the conveyor belt.
